Description
Salice G5E6S concealed runners are high-capacity, full-extension drawer runners designed for drawers with 13–16 mm side thickness. Part of the advanced Progressa system, they feature a fully integrated Smove soft-close mechanism for smooth, silent closing and a refined user experience.
Perfect for modern kitchens, wardrobes, and bespoke cabinetry, these runners deliver exceptional performance with tool-free adjustability and anti-rattle stability even under heavy loads.
🔧 Key Features:
- 🟢 Smove Soft-Close: Integrated damper slows closure silently
- 📦 Full Extension: Maximum access to drawer contents
- 🧲 Synchronized Sliding: Rack-and-pinion for stability and smoothness
- 🛡 Heavy-Duty: Dynamic load capacity of 45kg
- 🛠 Tool-Free Adjustments:
- Height: +2.5 mm
- Depth: ±3 mm
- Side: ±1.5 mm
- 📏 Drawer Side Thickness: 13–16 mm
- ✨ Finish: Bright zinc-plated
- 🇮🇹 Made in Italy
📐 Technical Specifications
| Feature | Details |
|---|---|
| Product Type | Concealed undermount drawer runner |
| Series | Progressa Smove |
| Extension | Full-extension |
| Closing Mechanism | Integrated soft-close (Smove) |
| Drawer Side Thickness | 13–16 mm |
| Dynamic Load Capacity | 45kg |
| Tool-Free Adjustments | Height +2.5 mm, Depth ±3 mm, Side ±1.5 mm |
| Finish | Bright zinc-plated |
🔢 Available SKUs
| Length | SKU | Min. Cabinet Depth |
|---|---|---|
| 250mm | G5E6S250XXF6 | 260mm |
| 300mm | G5E6S300XXF6 | 310mm |
| 350mm | G5E6S350XXF6 | 360mm |
| 400mm | G5E6S400XXF6 | 410mm |
| 450mm | G5E6S450XXF6 | 460mm |
| 500mm | G5E6S500XXF6 | 510mm |
| 550mm | G5E6S550XXF6 | 560mm |
🧩 Recommended Accessories
- AFCGXX3B – Front locking device (tool-free side and depth adjustment)
- AGLRXX3F – Tilt adjustment lever for +3 mm rear drawer rise (optional)
- AFSFXXB – Spacer for 12–13 mm sub-fronts (optional)
